birch, carrom board ply, english ply, white plywood- Laser Cutting - Interior Birch Plywood
An ultimate in performance and durability

You are viewing the application of birchply Laser Cutting Interior Birch Plywood Laser Cutting Interior Birch Plywood Laser Cutting Interior Birch Plywood Laser Cutting Interior Birch Plywood Laser Cutting Interior Birch Plywood

birch plywood, ply board, wardrob ply, kit ply, green ply, kitchen, almirah, cupbord

birch, carrom board ply, english ply, white plywood is a specially developed Birch Plywood with colourless synthetic resin adhesive for laser cutting, foundry pattern applications and is commonly used as die cutting plates.. It is equally suitable for several indoor uses and for interior applications in dry areas. The excellent strength properties of the panel enable die tools to be fabricated with accuracy in dimensions. The absence of any voids or gaps or open dead knots in intermediary layers and fortified bonding controls moisture movement as well as combustion gases emissions during laser cutting operations.

birch, carrom board ply, english ply, white plywood- Key Benefits

  • Highly wear resistant
  • Resistant to most aggressive environments, including chemicals
  • Durable
  • Hard surface
  • Easy to work with using conventional woodworking tools and fasteners
  • Environmentally friendly

Resistance to temperature variation: through a range of -40°C to +50°C (-40°F to +122°F) and is available in a variety of thicknesses and sizes

What does our promise of Efficiency mean to you

  • Products that improve your cost, material and energy efficiency
  • Reliable and timely deliveries
  • Local knowledge, support and service
  • Solutions for every application
  • Proven and documented technical data and environmental statement

birch, carrom board ply, english ply, white plywood- Certifications

Certified products are also available under the chain of custody programs on prior arrangement

birch, carrom board ply, english ply, white plywood- Properties

  • Moisture resistant, dimensionally accurate & stable.
  • Strong and light
  • CNC Routable and can be machined,
  • Meets EUTR standards,
  • Meets European E1 formaldehyde emission requirements (EN 120:1992) and also California ARB regulation P2

birch, carrom board ply, english ply, white plywood- Veneers

  • 100% natural whole piece or spliced Birch Veneers of 1.4mm thickness throughout the plywood without any gaps or open splits or joints.
  • Face veneer: Qualities B and/or BB as may be required.

birch, carrom board ply, english ply, white plywood- Bonding

  • Cross-bonded interior gluing according to EN 314-2 (Plywood - Bonding) class 1 interior.

Effect of humidity and moisture

  • Wood veneer is a living material and is subject to moisture movement according to surrounding conditions, which affects the flatness of panels. It is important to condition the panels to reach a moisture content near to the equilibrium of their permanent environment.

  • Like other wood-based panel products, Birch Plywood is also hygroscopic and its dimensions change in response to a change in humidity. A change of 1% in moisture content typically increases or decreases the length, width and thickness by 1% in dimensions and thickness. It is therefore desired that the edges are sealed with a suitable acrylic paint to prevent and/or control ingress of moisture and humidity and consequent swell in thickness and expansion in dimensions.

  • The recommended stocking conditions are 20°C and a RH of air of about 60%.

It must not be exposed to wet or high humidity conditions!

Storage conditions:

  • The recommended stocking conditions are 20°C and a RH of air of about 60%.

Availability options:

  • birch, carrom board ply, english ply, white plywood- Plywood is made in a range of thickness from 4mm to 40mm.

However, the commonly available Ex-Stock thickness is

  • 3mm x 3 ply
  • 4mm x 3 ply
  • 6mm x 5 ply
  • 8mm x 5 ply
  • 9mm x 7 ply
  • 12mm x 9 ply
  • 18mm x 13 ply
  • 21mm x 15 ply
  • 24mm x 17 ply
  • 30mm x 21 ply
  • 33mm x 23 ply
  • 35mm x 25 ply
  • 40mm x 29 ply.

The most commonly available dimension is 1525mm x 1525mm
Commonly available surface Grades are B/BB, BB/BB.
Other grades can also be had under prior arrangement.
Size tolerances for standard and cut-to-sizes panels ±1 mm.

Thicknesses and weights

  • Thicknesses and tolerances fulfils the requirements of EN 315 (Plywood - Tolerances for dimensions) and are in part stricter. Other thicknesses on request.
Nominal thickness (mm)
Number of plies
Min. thickness (mm)
Max. thickness (mm)
Weight
(kg/m 2) approx
3
3
3
3.4
2.1
4
3
3.8
4.2
2.8
6
5
6.1
6.9
4.4
8
6/7
7.8
8.5
5.5
9
7
8.8
9.5
6.1
12
9
11.5
12.5
8.2
16
11/12
15.8
16.5
10.9
18
13
17.1
18.1
12.2
21
15
20.0
20.9
14.3
24
17
22.9
23.7
16.3
30
21
29.1
30.5
20.3
33
23
32.0
33.4
22.3
40
29
39.2
40.5
27.1

Sizes and thicknesses relating to moisture content 8–12 %.

Technical Specification

Moisture resistance Normal, interior as per EN -314 (2) Class-1 Interior
Density, kg/m3 640-700
Moisture content, % 5-14
Plywood is produced under STO 00255177-001-2013 "General purpose plywood with birch face veneers."*



Preservatives

birch, carrom board ply, english ply, white plywood Plywood is made from natural Birch wood Veneers grown and harvested in Russia and is free from any toxic chemicals except resin. As is common knowledge, all wood products are susceptible to insects or termites and/or borers present in different climatic zones in the soil or buildings. It is recommended that the users are applying the coat of suitable chemicals or insecticides on all exposed surfaces of wood in addition to treatment of masonry foundations of the building where the Wood products are required to be use. Fipronil emulsified concentrate at about 3% is one such chemical and effective deterrent against insects and pests or termites in tropical climate zones. However, the application should be in accordance with manufacturers guidelines for effective results. Users own discretion in selection of appropriate chemical and its doses or frequency of such treatment is advised for satisfactory results in the light of experience gained over the period of time.

Strength Specifications

Subject
Thickness, mm
Index
Static bending strength,
N/mm2, not less
along the outer layer
grain
9-40
45
across the outer layer grain
30
Strength in tension along the grain, N/mm2, not less
3-8
30
Modulus of elasticity in static bending, N/mm2, not less along the grain
9-40
5000
across the grain
3000



DIN EPA carb compliant


Birch Ply
