pinepanls, osb board, osb, mdf, mdf board OSB 3 - Oriented Strand Board from Kronospan

Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB Pinepanels - Oriented Strand Board-OSB

mdf, mdf board

osb, osb board, mdf, pinepanels, mdf board Oriented Strand Board (OSB) produced by Kronospan in Romania (EC) is a performance based engineered, mat-formed panel product made of Spruce, Pine and Beech Wood strands, flakes or wafers and bonded with an exterior-type formaldehyde free PU binder under heat and pressure. High Moisture Resistant MDI/PMDI resin binders are combined with the strands to provide internal strength, rigidity and moisture resistance.

osb, osb board, mdf, pinepanels, mdf board OSB 3 meets or exceeds the performance standards of any Moisture resistant plywood and is also cost effective for uses in interior conditions.

osb, osb board, mdf, pinepanels, mdf board OSB 3 has excellent moisture tolerance and suitable in both dry and highly humid areas of applications and absolutely free from insects and termite infestations in its natural form even without any preservative treatment. In addition, OSB3 has exceptional dimensional stability and a uniform structure with no knots or core voids without any tendencies to warp, twist, cup or bend.

osb, osb board, mdf, pinepanels, mdf board OSB 3 is highly recommended as a structural wood panel and conforms to practically all international standards for applications in Buildings including sheathings and roofing, cabinetries and durable packaging.

osb, osb board, mdf, pinepanels, mdf board OSB 3 is also compliant California ARB regulations Phase 1 and 2, being exempted.

osb, osb board, mdf, pinepanels, mdf board is environment friendly solution in our times to save tropical hardwood forests from extinction and augment the initiatives of sustainable forestry by using the thinning of the plantations as its constituent wood.

Standard osb, osb board, mdf, pinepanels, mdf board OSB

EN 300 as applicable to OSB 3 - Load bearing boards for use in humid conditions.

Key Benefits osb, osb board, mdf, pinepanels, mdf board OSB

  • High performance and natural look
  • No Added Formaldehyde (NAF) resin bonded
  • Fresh indoor air quality,
  • Resistance to temperature variation: through a range of -40°C
    to +50°C (-40°F to +122°F), comes in a variety of thicknesses and sizes

What does our promise of Efficiency mean to you

  • Products that improve your cost, material and energy efficiency
  • Reliable and timely deliveries
  • Local knowledge, support and service
  • Solutions for every application
  • Proven and documented technical data and environmental statements

Properties osb, osb board, mdf, pinepanels, mdf board OSB

  • Dimensionally stable, accurate & stable.
  • Strong and light
  • Meets EUTR standards,

Bonding osb, osb board, mdf, pinepanels, mdf board OSB

  • Non-formaldehyde synthetic resin MDI/PMDI is used as binder in OSB 3. However, the natural formaldehyde in the veneer strands do emit formaldehyde but such emission is far below the limits set out in EN 13986.

Thermal conductivity

  • The thermal conductivity (l) of OSB as determined according to BS EN 12664 Thermal performance of building materials and products. Determination o f thermal resistance by means of guarded hot plate and heat flow meter methods. Dry and moist products of medium and low thermal resistance5 is 0.13 W/m.K for a mean density of 650 kg/m3 as set out in BS EN 13986.

Availability options:

Panel sizes commonly available is 2440mm x 1220mm in thickness 12mm & 18mm. Other dimensions can also be arranged with prior arrangement.

Effect of humidity and moisture

  • Wood Fibers is a living material and is subject to moisture movement according to surrounding conditions, which affects the flatness and thickness swell of panels. .It is important to condition the panels to reach a moisture content near to the equilibrium of their permanent environment. The recommended stocking conditions are 20°C and a RH of air of about 60%.

  • Wetting of OSB should be avoided. OSB3 is not waterproof; the term ‘moisture resistant’ applies to the adhesive binder which will not break down in the presence of moisture (within BS EN 300 limits).

  • Like other wood-based panel products, OSB is hygroscopic and its dimensions change in response to a change in humidity. A change of 1% in moisture content typically increases or decreases the length, width and
    thickness of the OSB by 1% in dimensions and thickness.

It must not be exposed to wet or high humidity conditions!

Storage conditions:

  • The recommended stocking conditions are 20°C and a RH of air of about 60%. The boards should be stored in their intended installation area for a minimum of 48 hours to acclimatise to the surrounding temperature and humidity. Check for any damages before fitting.

Precautions and General Advice

  • Wetting of OSB must be avoided. OSB3 is not waterproof; the term ‘moisture resistant’ applies to the adhesive binder which will not break down in the presence of moisture (within BS EN 300 limits).

  • All common woodworking tools can be used successfully with Kronospan OSB 3. As a general rule, cutting speeds should be lower than for conventional wood. Carbide or diamond tipped blades and cutters are recommended because of their longer cutting life.

  • Boards with straight edges need 2-3 mm dilatation gap at the edges of the boards for possible moisture expansion, depending upon the assessment of risk.
    by the users.

  • Corrosion resistant fasteners should be used where OSB is part of a load bearing structure. Structural fastening systems are only permitted if their use has been approved by the manufacturer.

  • Guidance on the use of OSB in load-bearing applications is given in DD CEN/TS 12872.

  • OSB 3 boards must be free from direct exposure to weather conditions, sun light and rains to prevent from weathering and decay.

  • Physical wetting of all grades of OSB should be avoided. When wet, OSB will increase appreciably in thickness and start the weathering and decay process.

  • OSB will not normally be attacked by wood-boring insects common in temperate climates as these are susceptible to fungal attack under prolonged wet conditions.

General Properties of OSB

PROPERTY
TEST METHOD
UNIT
VALUE
Tolerances on nominal dimensions Length & Width
EN 324-1
mm
± 3.0
Thickness 1,2
EN 324-1
mm
± 0.3 (sanded), ± 0.8 un-sanded
Edge straightness tolerance 1
EN 324-2
mm/m
1.5
Squareness tolerance 1
EN 324-2
mm/m
2
Moisture content
EN 322
%
2 - 12%
Tolerance on the mean density within a board
EN 323
%
± 15
Formaldehyde release according to EN 13986 3
EN 120
mg/100g
E1 ≤8mg/100g

1These values are characterised in the material corresponding to a relative humidity of 65% and temperature of 20° C
2These values are characterised between and within boards
3Perforator values are related to boards with moisture of 6,5%. In the case of boards with different moisture content the perforator value is recalculated.

Properties for load bearing boards for the use in humid conditions (type OSB 3):

PROPERTY
TEST METHOD UNIT
NOMINAL THICKNESS, mm
6 to 10 >10 to <18 18 to 25 >25 to 32
Bending Strength - major axis EN 310 N/mm2
22
20
18
16
Bending Strength - minor axis EN 310 N/mm2
11
10
9
8
Bending strength after cyclic test - major axis1, 2 EN 321 N/mm2
9
8
7
6
MOE in bending - major axis EN 310 N/mm2
3500
MOE in bending - minor axis EN 310 N/mm2
1400
Internal Bond EN 319 N/mm2
0.34
0.32
0.30
0.29
after cyclic test 1
EN 321 N/mm2
0.18
0.15
0.13
0.10
after boil test 3;
EN 321 N/mm2
0.15
0.13
0.12
0.6
Swelling in thickness - 24h EN 322
%
15

1Option 1 for moisture resistance requirement
2For the calculation of bending strength after cyclic test, the thickness taken to account is the thickness measured after the cyclic test
3Option 2 for moisture resistance requirement

Certifications:

osb, osb board, mdf, pinepanels, mdf board OSB is also available under chain of custody programs on prior arrangement. Please check availability.

osb, osb board, mdf, pinepanels, mdf board OSB is also certified for conformity with California ARB regulation No. 93120.2 as applicable to Phase 2. Please check availability.

DIN EPA carb compliant


pinepanels osb board

Related Document
pinepanels mdf boards View our OSB Product Catalogue
osb boards Oriented Strand Board - MSDS
osb boards  OSB Technical Information & Physical  Properties
osb boards Kronobuild load-bearing values of OSB 3 & OSB 4
mdf boards OSB- Flammability Test Report
osb boards Environmental Policy
osb boards Oriented Strand Boad - FAQs
osb boards OSB - European Regulation on Formaldehyde
pdf CARB Indoor Air Quality Guideline

User Guide Documents
osb boards OSB - In Humid Environment
mdf boards OSB - A new dimension in strength
osb boards OSB - An Industrial Solution
osb boards OSB Design Manual
osb boards OSB - Fire Performance
osb boards OSB Performance by Design
osb boards OSB - Fungi control
osb boards OSB vs. Plywood
